Tech specs
Marque
Cisco
Gamme de produits
Catalyst Cisco
Modèle
1300-8FP-2G
Fabricant
Cisco Systems
Vitesse de l'horloge
1,4 GHz
Marque de processeur
ARM
Flash Memory Installed
512 mégaoctets
Technologie de la mémoire
DDR4 SDRAM
Mémoire vive installée
1 Go
Commutation avancée
Couche 3
Conforme aux normes
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802,3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Fonctionnalités
ACL support, Address Resolution Protocol, ARP inspection, ATP, Auto Surveillance VLAN, Boot integrity, BOOTP support, BPDU Guard, Broadcast Storm Control, Cable length detection, Chip guard, Cisco NG PnP Protocol, CLI management, CPE VLAN, DAD, DAI, DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 guard, DiffServ support, DNS client, DoS attack prevention, DoS protection, DSCP based CoS, Dynamic routing, Eco-friendly button, Energy-Efficient Ethernet (EEE), Fanless, FHS, GARP, Guest VLAN, GVRP, High Availability, HoL Blocking Prevention, IGMP proxy, IGMP querier, IGMP snooping, IP source guard, IPMB, IPv4 and IPv6 dual stack, iSCSI traffic optimization, LACP, LAG, Layer 3 routing, LLDP, LLDP-MED, Loopback detection, MAC address authentication, MAC based VLAN, MLD proxy, MLD snooping, MSTP support, Multicast Storm Control, MVR, NDP, Path MTU discovery, Persistent PoE, PoE scheduling, Port mirroring, Port Security, Private VLAN, Protocol-based VLANs support, PVE, PVST+, Q-in-Q tunneling, QoS, RA guard, Reset button, Router advertisement guard, RPVST+, RSPAN, RSTP, SCP, SCT, sFlow, SSD, Storm Control, STP loop guard, STP Root Guard, STP support, TCP congestion, Telnet client, Telnet server, Time-based port operation, ToS, TPID, Trustworthy systems, UDLD, UDP, Unicast Storm Control, Unknown Storm Control, VLAN management, VLAN mirroring, VLAN support, Web authentication, WRR, Zero-Touch Deployment
Form Factor (Hubs & Switches)
Montage sur bâti
Support de cadre Jumbo
9000 octets
Taille du tableau des adresses MAC
16000 entries
Administrable
Oui
Budget d’alimentation par Ethernet (PoE)
120 watts
Ports
8
Power Over Ethernet (PoE)
PoE+
Type de produit
Commutateur
Gestion à distance
CLI, DHCP, HTTP, HTTPS, ICMP, RADIUS, RMON, SCP, SNMP, SNMP 2c, SNMP 3, SSH, SSH-2, Syslog, Telnet, TFTP
Protocole de routage
Bounjour, CIDR, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, MSTP, Policy-based routing (PBR), RIP-2, RSTP, Static IP routing, STP
Indicateurs d'état
Link/activity/speed, PoE, System
Sous-catégorie
Concentrateurs et commutateurs réseau
Switching Type
Gigabit Ethernet
Interface prévue
1 x console RJ-45, 1 x USB-C console, 2 x 1000Base-X RJ-45/SFP, 8 x 10/100/1000 Base-T (PoE+) RJ-45
Nombre de ports
8
Type de port
10/100/1000 (PoE+)
Ports Type (2nd)
Combo Gigabit SFP/RJ-45
Fréquence
50-60 hertz
Required Voltage
AC 100-240 volt
Chiffrement
MD5, SSL
Plage d'humidité de stockage
5 - 90% RH (non-condensing)
Température d'exploitation maximale
50 degrés Celsius
Température maximale de stockage
70 degrés Celsius
Température d'exploitation minimale
-5 degré Celsius
Température de stockage minimale
-25 degré Celsius
MTBF
1 786 412 heures
Humidité de fonctionnement
5 - 90% RH (non-condensing)
Méthode d'authentification
RADIUS, TACACS+
Capacité
Règles ACL: 1024, IGMP multicast groups: 2000, IPv4 interfaces: 128, IPv4 routes (static): up to 990, Link aggregation groups: 8, Link aggregation ports: 8, MSTP instances: 8, Packet buffer size: 1,5 MB, Priority queues: 8, RPVST+ instances: 126, VLAN IDs: 4093
Type de périphérique
Alimentation électrique interne
Quantité livrée
1
Performance
Forwarding rate (64-byte packets): 14,88 Mpps, Switching capacity: 20 Gbits/s
Ports (2nd) Quantity
2
Accessoires inclus
Mounting kit, Pointer card
Hauteur
4,4 centimètres
Poids
2,59 kilogrammes
Largeur
26,8 centimètres
Profondeur
27,2 centimètres
Catégorie couleur
Blanc
Conforme aux normes
CSA 22,2, FCC CFR47 Part 15, Plug and Play, RFC1042, RFC1071, RFC1123, RFC1141, RFC1155, RFC1157, RFC1213, RFC1215, RFC1286, RFC1350, RFC1442, RFC1451, RFC1493, RFC1533, RFC1541, RFC1542, RFC1573, RFC1624, RFC1643, RFC1700, RFC1757, RFC1867, RFC1907, RFC1981, RFC2011, RFC2012, RFC2013, RFC2030, RFC2131, RFC2132, RFC2233, RFC2460, RFC2576, RFC2616, RFC2618, RFC2665, RFC2666, RFC2674, RFC2737, RFC2819, RFC2863, RFC3164, RFC3176, RFC3411, RFC3412, RFC3413, RFC3414, RFC3415, RFC3416, RFC3484, RFC3595, RFC4007, RFC4291, RFC4293, RFC4330, RFC4443, RFC4861, RFC4862, RFC5214, RFC768, RFC783, RFC791, RFC792, RFC793, RFC813, RFC826, RFC854, RFC855, RFC856, RFC858, RFC879, RFC894, RFC896, RFC919, RFC920, RFC922, RFC950, RFC951, UL 62368, WEEE
Certifié ENERGY STAR®
Non
Conforme à EPEAT
Non
Certifié TCO
Non
Détails du service et du support
Garantie limitée - durée de vie - temps de réponse : next business day, Technical support - consultation - 1 an
Garantie limitée
Limited Lifetime
