Tech specs
Marque
Aruba
Gamme de produits
HPE Aruba
Modèle
2930F 24G PoE+ 4SFP+
Fabricant
Aruba
Vitesse de l'horloge
1,016 GHz
Marque de processeur
ARM
Type processeur
Cortex-A9
Processors Installed
1
Flash Memory Installed
4 Go
Technologie de la mémoire
DRAM synchrone (SDRAM) DDR3
Mémoire vive installée
1 Go
Commutation avancée
Couche 3
Conforme aux normes
IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Fonctionnalités
Access Control List (ACL) support, ARP support, BOOTP support, Class of Service (CoS), CPU protection, DHCP protection, DHCP server, DHCP support, DiffServ support, Dynamic ARP protection, Dynamic VLAN Support (GVRP), Flow control, Full duplex capability, ICMP Router Discovery Protocol (IRDP), IGMP snooping, Internet Control Message Protocol (ICMP), IPv6 support, Jumbo Frames support, Link Aggregation Control Protocol (LACP), LLDP support, MAC address lockout, Management Information Base (MIB), Management Information Base (MIB) II, Multiple Spanning Tree Protocol (MSTP) support, Multiple VLAN Registration Protocol (MVRP), Neighbor Discovery Protocol (NDP), OpenFlow support, Quality of Service (QoS), sFlow, SNTP support, Spanning Tree Protocol (STP) support, STP Root Guard, Syslog support, Type of Service (ToS), Uni-Directional Link Detection (UDLD), Virtual Extensible LAN (VXLAN), VLAN support
Form Factor (Hubs & Switches)
Montage sur bâti
Taille du tableau des adresses MAC
Entrées 32K
Administrable
Oui
Budget d’alimentation par Ethernet (PoE)
370 watts
Ports
24
Power Over Ethernet (PoE)
PoE+
Type de produit
Commutateur
Gestion à distance
CLI, RMON 1, SNMP, SNMP 1, SNMP 2, SNMP 2c, SNMP 3, SSH, SSH-2, Telnet, XRMON
Protocole de routage
BGP, CIDR, IGMP, IGMPv2, IGMPv3, MLD, OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2, RIPng, Static IP routing, Static IPv4 routing, Static IPv6 routing
Empilable
Empilable
Sous-catégorie
Concentrateurs et commutateurs réseau
Switching Type
Gigabit Ethernet
Connecteurs d'emplacement
1 (total) / 1 (free) x expansion slot
Interface prévue
1 x serial (console), 24 x 1000Base-T RJ-45 PoE+, 4 x Gigabit / 10Gbit LAN SFP+
Nombre de ports
24
Type de port
10/100/1000 (PoE+)
Ports Type (2nd)
1 Gigabit / 10 Gigabit SFP+ (liaison montante)
Power Supplies Installed
1
Certification 80 PLUS
80 PLUS Argent
Software Type
Command Line Interface (CLI), HP Intelligent Management Center, HP Web browser
Chiffrement
MD5, SSL
Plage d'humidité de stockage
15 - 90 % (sans condensation)
Température d'exploitation maximale
45 degrés Celsius
Température maximale de stockage
70 degrés Celsius
Température d'exploitation minimale
0 degrés Celsius
Température de stockage minimale
-40 degré Celsius
Humidité de fonctionnement
15 - 95 % (sans condensation)
Périphériques pris en charge
4
Méthode d'authentification
CHAP, PAP, RADIUS, TACACS, TACACS+
Capacité
Entrées de table de routage IPv4: 10000, IPv6 routing table entries: 5000, Jumbo frame size: 9220
Pays
États-Unis
Type de périphérique
Alimentation électrique interne
Installed Devices/Modules
0
Localisation
Anglais
Quantité livrée
1
Performance
Latency (1 Gbps): 3,8 µs, Latency (10 Gbps): 1,6 µs, Switching capacity: 128 Gbps, Throughput: 95,2 Mpps
Ports (2nd) Quantity
4
Accessoires inclus
4 bumper feet, 4 mounting ears, Cable tie, Mounting screws
Hauteur
4,39 centimètres
Hauteur (Unités de rack)
1
Poids
3,9 kilogrammes
Largeur
44,25 centimètres
Profondeur
30,42 centimètres
Catégorie couleur
Noir
Conforme aux normes
CISPR 22 Class A, CISPR 24, CNS 13438, CSA C22.2 No. 60950-1-07 Second Edition, EN 55022:2010, EN 55024:2010, EN 60825-1:2007, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, FCC CFR47 Part 15 A, ICES-003 Class A, IEC 60825-1:2007, IEC 60950-1:2005 + A1:2009 + A2:2013, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, UL 60950-1 Second Edition, VCCI Class A
Certifié ENERGY STAR®
Non
Conforme à EPEAT
Non
Certifié TCO
Non
Détails du service et du support
Garantie limitée - durée de vie
Garantie limitée
Limited Lifetime
